F695 2RS ABEC-7 Bearing
Rain & Dew Model: F695 2RS
Accuracy Class: ABEC-7
Bearing Type: Flange Ball Bearing
Bearing Material GCr15 Bearing Steel
Ball Material: GCr15 Bearing Steel
Seal Type: Rubber Seal Cover
Shaft diameter:5 mm
Inner diameter (d):5 mm
Seat hole: 13mm
Outer diameter (D): 13mm
Width (B):4mm
Flange OD:15mm
Flange thickness:1mm
Dynamic load (Cr) (N): 916
Static load (Cor) (N): 346
Limiting speed (oil) (X1000 RPM):46
Speed limit (oil) (X1000 RPM): 52
Clearance level: C0
Number of balls: 8
Weight: 2.65g
